Feature:
|
Nominal Voltage |
12V |
|
|
Nominal Capacity(10HR) |
200AH |
|
|
Dimension |
Length |
522±3mm |
|
Width |
234±2mm |
|
|
Container Height |
223±2mm |
|
|
Total Height (with Terminal) |
229±2mm |
|
|
Approx Weight |
Approx 62.5 Kg |
|
|
Terminal |
T11 |
|
|
Container Material |
ABS |
|
|
Rated Capacity |
20hr ,1.80V/cell,25℃/77℉ |
209.1 AH/10.4A |
|
10hr,1.80V/cell,25℃/77℉ |
200.0 AH/20.0A |
|
|
5hr,1.75V/cell,25℃/77℉ |
173.0 A H/34.6A |
|
|
3hr,1.75V/cell,25℃/77℉ |
157.2 AH/52.4A |
|
|
1hr,1.60V/cell,25℃/77℉ |
122.8 AH/122.8A |
|
1. High-strength ABS plastic battery slot and cover, compact structure. good resistance.
2. Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.
3. good opacity, strong charge acceptance.
4. New electrode plate manufacturing process, high utilization rate of active materials.
5. Multi-layer sealing technology and special sealing glue ensure that the battery has no leakage, no acid mist .
Parameter:
Feature:
1. High-strength ABS plastic battery slot and cover, compact structure. good resistance.
2. Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.
3. good opacity, strong charge acceptance.
4. New electrode plate manufacturing process, high utilization rate of active materials.
5. Multi-layer sealing technology and special sealing glue ensure that the battery has no leakage, no acid mist .
