| Nominal Voltage | 12.8 V |
| Nominal Capacity | 105 Ah |
| Energy | 1344 Wh |
| Resistance | ≤0.5mΩ |
| Efficiency | 99% |
| Self Discharge | ≤3% per month |
51.2V200Ah- 10.24KWh 48V 200AH lifepo4 Wall-Mounted battery, Power wall Wall-Mounted Lithium-ion Battery Pack
24V 50AH Lifepo4 Lithium Battery Pack for RVs, Caravans, Motorhomes
Lifepo4 Lithium Battery Factory 12V 24V 48V 96V from 7AH to 1000AH
12V 100AH Lifepo4 Lithium Battery Pack for RVs, Caravans, Motorhomes
24V 100AH Lifepo4 Battery for RV, Motorhomes, Caravans, solar trailer, residential solar off grid
| Recommended Charge Current | 25A - (Range: 0.2C-0.5C) |
| Maximum Charge Current | 100 A (1C) |
| Recommended Charge Voltage | 14.6 V |
| BMS Charge Voltage Cut-Off | 14.8 V (3.9 ±0.025 vpc) (1.1 ±0.4 s) |
| Reconnect Voltage | 14.2 V (3.8 ±0.05 vpc) |
| Balancing Voltage | 13.62 V (3.6 ±0.025 vpc) |
| Maximum Continuous Discharge Current | 100A (150A BMS) |
| Peak Discharge Current | 250A（3-5s） |
| BMS Discharge Current Cut-Off | 450A(300ms) |
| Recommended Low Voltage Disconnect | 10.5 V |
| BMS Discharge Voltage Cut-Off | 9.4 V (2.0 ±0.08 vpc) (140 ±60 ms) |
| Reconnect Voltage | 10.2 V (2.3 ±0.1 vpc) |
| Short Circuit Protection | 200-300 µs |
| Discharge Temperature | -4 to 130 ºF (-20 to 55 ºC) |
| Charge Temperature | 32 to 130 ºF (0 to 55 ºC) |
| Storage Temperature - 1 month | -4 to 113 ºF (-20 to 45 ºC) |
| Storage Temperature - 1 year | 32 to 95 ºF (0 to 35 ºC) |
| BMS High Temperature Cut-Off | 176 ºF (80 ºC) |
| Reconnect Temperature | 122 ºF (50 ºC) |
| BMS Low Temperature Cut-Off (Charging) | 32 ºF (0 ºC) |
| Reconnect Temperature (Charging) | 41 ºF (5 ºC) |
| Over Current Protection | yes |
| Under Voltage Protection | yes |
| Over Voltage Protection | yes |
| Overload Protection | yes |
| High Temperature Protection | yes |
| Low Temperature Protection | 32 ºF (0 ºC) / 41 ºF (5 ºC) |
| Short Circuit Protection | yes |
| Dimensions (L x W x H) | 12.8 x 6.7 x 8.7” (325 x 170 x 220 mm) |
| Weight | 24.25lbs (11 kg) |
| Terminal Type | M8 （20mm） |
| Terminal Torque | 10 ~12 N-m |
| Case Material | ABS |
| Enclosure Protection | IP65 |
| Cell Type - Chemistry | Prismatic - LiFePO4 |
| MSDS Datasheet | MSDS |
| UN38.3 | DG61 |
| CE Certification | EN61000-6-1, EN61000-6-3 |
| ROHS Certification | ROHS |
| FCC Certification | Part15B |
| IEC62619 documentation or 49 CFR | IEC62619 / 49 CFR 173.185 |
| IMDG Code | UN3840 / Class 9 |
| Brand | EVE Energy Co., Ltd |
| Product | Prismatic Aluminum-clad LFP Battery |
| Model | LF105 |
| Specification | 3.2 V / 105 Ah |
| Cell / BMS Impact Protection | Large Foam Inserts as shown |
| Cable Size | All cable sizes capable of meeting all specs set forth by BMS |
| Cable Color | Color coded (Red/Black/Blue) |
| Low Temperature Probe | Probe placed on cells / wire attached to BMS |
| Model | 3SABM0-H02 (LFP-4S-150A) |
| Maximum Continous Discharge Current | 150A (BMS support Max continous current 150A ) |
| Cell Balancing | 3.4V (13.6V) |
| Over Current Protection | yes |
| Under Voltage Protection | yes |
| Over Voltage Protection | yes |
| Overload Protection | yes |
| High Temperature Protection | yes |
| Low Temperature Protection | 0C Disconnect, 5C Reconnect |
| Short Circuit Protection | yes |
| Dimensions (L x W x H) | 10.25 x 6.7 x 8.25” (260 x 168 x 209 mm) |
| Terminal Type | M8 (20mm) |
| Terminal Torque | 10 ~12 N-m |
| Case Material | ABS |
| Enclosure Protection | IP65 |
| Front Graphics Label | 160 x 230 mm |
| Dimensions (L x W x H) | 12.21 x 8.66 x 10.43" (310 x 220 x 265mm) |
| Weight | 29.56 lbs (12.5 kg) |
Packing
Carton + Wooden + Pallet
Shipping
Express | By air | By sea
