Parameter:
Nominal Voltage |
12V |
|
Nominal Capacity(10HR) |
100AH |
|
Dimension |
Length |
407±3mm |
Width |
173±2mm |
|
Container Height |
240±2mm |
|
Total Height (with Terminal) |
250±2mm |
|
Approx Weight |
Approx 29.5Kg (64.9 Ibs) |
|
Terminal |
T11 |
|
Container Material |
ABS |
|
Rated Capacity |
20hr ,1.80V/cell,25℃/77℉ |
110.0 AH/5.50A |
10hr,1.80V/cell,25℃/77℉ |
100.0 AH/10.0A |
|
5hr,1.75V/cell,25℃/77℉ |
87.2 A H/17.4A |
|
3hr,1.75V/cell,25℃/77℉ |
79.4 AH/26.5A |
|
1hr,1.60V/cell,25℃/77℉ |
61.1 AH/61.1A |
Feature:
1. High-strength ABS plastic battery slot and cover, compact structure. good resistance.
2. Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.
3. good opacity, strong charge acceptance.
4. New electrode plate manufacturing process, high utilization rate of active materials.
5. Multi-layer sealing technology and special sealing glue ensure that the battery has no leakage, no acid mist .
