| Nominal Voltage | 2V | |
| Nominal Capacity(10HR) | 700AH | |
| Dimension | Length |
225±3mm (20.55 inches) |
| Width | 181±2mm (9.45 inches) | |
| Container Height | 346±2mm (8.58 inches) | |
| Total Height (with Terminal) | 350±2mm (8.81 inches) | |
| Approx Weight | Approx 41.2 Kg (90.8 Ibs) | |
| Terminal | T11 | |
| Container Material | ABS | |
| Rated Capacity | 20hr ,1.80V/cell,25℃/77℉ | 736.0 AH/36.8A |
| 10hr,1.80V/cell,25℃/77℉ | 700.0 AH/70.0A | |
| 5hr,1.75V/cell,25℃/77℉ | 598.5 A H/119.7A | |
| 3hr,1.75V/cell,25℃/77℉ | 525.0 AH/175.0A | |
| 1hr,1.60V/cell,25℃/77℉ | 420.0 AH/420.0A | |
Feature:
1. High-strength ABS plastic battery slot and cover, compact structure. good resistance.
2. Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.
3. good opacity, strong charge acceptance.
4. New electrode plate manufacturing process, high utilization rate of active materials.
5. Multi-layer sealing technology and special sealing glue ensure that the battery has no leakage, no acid mist .
